16进制和ASCII的互相转换
*/
#include <string.h>
#include <stdio.h>
#include <errno.h>
#include <stdlib.h>
typedef double flo64; // Double precision floating point
typedef double * pflo64;
typedef float flo32; // Single precision floating point
typedef float * pflo32;
typedef signed int int32s; // Signed 32 bit quantity
typedef signed int * pint32s;
typedef unsigned int int32u; // Unsigned 32 bit quantity
typedef unsigned int * pint32u;
typedef signed short int16s; // Signed 16 bit quantity
typedef signed short* pint16s;
typedef unsigned short int16u; // Unsigned 16 bit quantity
typedef unsigned short* pint16u;
typedef signed char int8s; // Signed 8 bit quantity
typedef signed char * pint8s;
typedef unsigned char int8u; // Unsigned 8 bit quantity
typedef unsigned char * pint8u;
#define MAX_FRAM_LEN 256
unsigned char halfbyte_2ascii_biggercase(unsigned char half_byte)
{
//printf("1half_byte:%02x\n", half_byte);
//printf("1half_byte:%02x, %c\n", half_byte + '0', half_byte + '0');
//大写形式
if(half_byte >= 9) //0xa的十进制是10.字符'A'的16进制为0x41， 字符'a'的16进制为0x61，
half_byte += 39;
//printf("2half_byte:%02x\n", half_byte);
//printf("2half_byte + '0':%02x,%c\n", half_byte + '0', half_byte + '0');
return half_byte + '0';
}
unsigned char halfbyte_2ascii_lowercase(unsigned char half_byte)
{
//printf("1half_byte:%02x\n", half_byte);
//printf("1half_byte:%02x, %c\n", half_byte + '0', half_byte + '0');
#if 1
//大写形式
if(half_byte >= 9) //0xa的十进制是10.字符'A'的16进制为0x41， 字符'a'的16进制为0x61，
half_byte += 7;
#endif
//printf("2half_byte:%02x\n", half_byte);
//printf("2half_byte + '0':%02x,%c\n", half_byte + '0', half_byte + '0');
return half_byte + '0';
}
/*
16进制转16进制ASCII(大写)
hex 30 30 30 33 30 30 32 30 30 30 30 32 3d 3b ==>ascii hex: 30 30 30 33 30 30 32 30 30 30 30 32 64 62
示例：unsigned char ascii1[30]={0};
unsigned char ascii2[30]={0};
int ascii1_len = 7;
int ascii2_len = 7;
memcpy(ascii1, "\x00\x03\x00\x20\x00\x02\xdb", ascii1_len);
memcpy(ascii2, "\x00\x03\x00\x20\x00\x02\xdb", ascii2_len);
hex2ascii_lowercase(ascii1, &ascii1_len);
printf("ascii1_len:%d,%02x\n", ascii1_len, ascii1_len);
for(int i = 0; i< ascii1_len; i++)
{
printf("%02x ", ascii1[i]);
}
printf("\n");
hex2ascii_biggercase(ascii2, &ascii2_len);
printf("ascii2_len:%d,%02x\n", ascii2_len, ascii2_len);
for(int i = 0; i< ascii2_len; i++)
{
printf("%02x ", ascii2[i]);
}
printf("\n");
结果：
ascii1_len:14,0e
30 30 30 33 30 30 32 30 30 30 30 32 44 42
ascii2_len:14,0e
30 30 30 33 30 30 32 30 30 30 30 32 64 62
*/
unsigned char hex2ascii_biggercase(unsigned char *pbuf,unsigned int *count)
{
unsigned char temp1,temp2,*pdata;
unsigned int i = 0,j = 0,sum;
if(pbuf == 0 || count == 0 || *count == 0) return 1;
if((pdata = (unsigned char *)malloc((*count+1)*sizeof(unsigned char))) == NULL) return 2; //内存申请,目前采用堆空间,长度512字节
sum = (*count);
/*每个字节用2个ASCII表示*/
for(i = 0; i < sum; i++)
{
temp1 = ((pbuf[i] & 0xF0) >> 4);
temp2 = (pbuf[i] & 0x0F);
pdata[j++] = halfbyte_2ascii_biggercase(temp1);
pdata[j++] = halfbyte_2ascii_biggercase(temp2);
}
*count = j; //转译后的总长度
memcpy(&pbuf[0],pdata,j); //转译后内容拷贝
/*释放内存*/
free(pdata);
pdata = NULL;
return 0;
}
/*
16进制转16进制ASCII(小写)
hex 3a 00 03 00 20 00 02 db 0d 0a ==>ascii hex: 30 30 30 33 30 30 32 30 30 30 30 32 44 42
示例：
unsigned char ascii1[30]={0};
unsigned char ascii2[30]={0};
int ascii1_len = 7;
int ascii2_len = 7;
memcpy(ascii1, "\x00\x03\x00\x20\x00\x02\xdb", ascii1_len);
memcpy(ascii2, "\x00\x03\x00\x20\x00\x02\xdb", ascii2_len);
hex2ascii_lowercase(ascii1, &ascii1_len);
printf("ascii1_len:%d,%02x\n", ascii1_len, ascii1_len);
for(int i = 0; i< ascii1_len; i++)
{
printf("%02x ", ascii1[i]);
}
printf("\n");
hex2ascii_biggercase(ascii2, &ascii2_len);
printf("ascii2_len:%d,%02x\n", ascii2_len, ascii2_len);
for(int i = 0; i< ascii2_len; i++)
{
printf("%02x ", ascii2[i]);
}
printf("\n");
结果：
ascii1_len:14,0e
30 30 30 33 30 30 32 30 30 30 30 32 44 42
ascii2_len:14,0e
30 30 30 33 30 30 32 30 30 30 30 32 64 62
*/
int8u hex2ascii_lowercase(int8u *pbuf,unsigned int *count)
{
int8u temp1,temp2,*pdata;
unsigned int i = 0,j = 0,sum;
if(pbuf == 0 || count == 0 || *count == 0) return 1;
if((pdata = (int8u *)malloc((*count+1)*sizeof(int8u))) == NULL) return 2; //内存申请,目前采用堆空间,长度512字节
sum = (*count);
/*每个字节用2个ASCII表示*/
for(i = 0; i < sum; i++)
{
temp1 = ((pbuf[i] & 0xF0) >> 4);
temp2 = (pbuf[i] & 0x0F);
pdata[j++] = halfbyte_2ascii_lowercase(temp1);
pdata[j++] = halfbyte_2ascii_lowercase(temp2);
}
*count = j; //转译后的总长度
memcpy(&pbuf[0],pdata,j); //转译后内容拷贝
/*释放内存*/
free(pdata);
pdata = NULL;
return 0;
}
/*
计算lrc校验，自研485温湿度用。
src:源字符串
start:起始下标
len:参数校验的有效数据长度
lrc:结果
示例：
unsigned char lsrc = 0;
unsigned char src[]="\x3A\x00\x03\x00\x20\x00\x02\xDB\x0D\x0A";
lsrc = count_lrc(src, 1, 6);
printf("lsrc:%d,%02x\n", lsrc, lsrc);
*/
unsigned char count_lrc(unsigned char *src, int start, int len)
{
unsigned char sum = 0;
unsigned char result = 0;
for(int i = start; i<= len; i++)
{
//printf("src[%d]:%d,%02x\n", i, src[i], src[i]);
sum+=src[i];
}
result = ~sum+1;
//printf("sum:%d,%02x\n", sum, sum);
//printf("result:%d,%02x\n", result, result);
return result;
}
/*
把modbus ascii数据转换成16进制（不改变原始数据）
pbuf：原始数据 16进制显示：3A 30 30 30 33 30 30 32 30 30 30 30 32 64 62 0D 0A ，对应字符串:000300200002db
src_len：原始数据长
dest：目标 16进制显示：3a 00 03 00 20 00 02 db 0d 0a
dest_len：目标长
例：
unsigned char p[]="\x3A\x30\x30\x30\x33\x30\x30\x32\x30\x30\x30\x30\x32\x64\x62\x0D\x0A";
int src_len = 17;
int dest_len = 0;
convert_modbus_ascii_2hex(p, src_len, dest, &dest_len);
printf("dest_len:%d,%02x\n", dest_len, dest_len);
for(int i = 0; i< dest_len; i++)
{
printf("%02x ", dest[i]);
}
printf("\n");
结果：
dest_len:10,0a
3a 00 03 00 20 00 02 db 0d 0a
*/
unsigned char convert_modbus_ascii_2hex(unsigned char *pbuf,int src_len, unsigned char *dest, int *dest_len)
{
int len_befor_after = 2;
unsigned char *pdata,temp1,temp2;
int32u i=0,j=0,sum=0;
if(pbuf==0 || src_len==0) return 1;
if((pdata = (unsigned char *)malloc((src_len+1)*sizeof(unsigned char))) == NULL) return 2; //内存申请,目前采用堆空间
memcpy(dest,pbuf,src_len);
sum = (src_len - len_befor_after); //帧头不参与
for(i = 1; i < sum; i+=2)
{
//printf("1pbuf[%d]:%02x\n", i, pbuf[i]);
switch(pbuf[i])
{
case 0x20: //代表空格
temp1 = 0x00;
break;
case 0x30:
temp1 = 0x00;
break;
case 0x31:
temp1 = 0x01;
break;
case 0x32:
temp1 = 0x02;
break;
case 0x33:
temp1 = 0x03;
break;
case 0x34:
temp1 = 0x04;
break;
case 0x35:
temp1 = 0x05;
break;
case 0x36:
temp1 = 0x06;
break;
case 0x37:
temp1 = 0x07;
break;
case 0x38:
temp1 = 0x08;
break;
case 0x39:
temp1 = 0x09;
break;
case 0x41:
temp1 = 0x0A;
break;
case 0x42:
temp1 = 0x0B;
break;
case 0x43:
temp1 = 0x0C;
break;
case 0x44:
temp1 = 0x0D;
break;
case 0x45:
temp1 = 0x0E;
break;
case 0x46:
temp1 = 0x0F;
break;
case 0x61:
temp1 = 0x0a;
break;
case 0x62:
temp1 = 0x0b;
break;
case 0x63:
temp1 = 0x0c;
break;
case 0x64:
temp1 = 0x0d;
break;
case 0x65:
temp1 = 0x0e;
break;
case 0x66:
temp1 = 0x0f;
break;
default:
temp1 = 0;
break;
}
//printf("2pbuf[%d]:%02x\n", i+1, pbuf[i+1]);
switch(pbuf[i+1])
{
case 0x20: //代表空格
temp2 = 0x00;
break;
case 0x30:
temp2 = 0x00;
break;
case 0x31:
temp2 = 0x01;
break;
case 0x32:
temp2 = 0x02;
break;
case 0x33:
temp2 = 0x03;
break;
case 0x34:
temp2 = 0x04;
break;
case 0x35:
temp2 = 0x05;
break;
case 0x36:
temp2 = 0x06;
break;
case 0x37:
temp2 = 0x07;
break;
case 0x38:
temp2 = 0x08;
break;
case 0x39:
temp2 = 0x09;
break;
case 0x41:
temp2 = 0x0A;
break;
case 0x42:
temp2 = 0x0B;
break;
case 0x43:
temp2 = 0x0C;
break;
case 0x44:
temp2 = 0x0D;
break;
case 0x45:
temp2 = 0x0E;
break;
case 0x46:
temp2 = 0x0F;
break;
case 0x61:
temp2 = 0x0a;
break;
case 0x62:
temp2 = 0x0b;
break;
case 0x63:
temp2 = 0x0c;
break;
case 0x64:
temp2 = 0x0d;
break;
case 0x65:
temp2 = 0x0e;
break;
case 0x66:
temp2 = 0x0f;
break;
default:
temp2 = 0;
break;
}
pdata[j++] = ((temp1 & 0x0F) << 4 | temp2); //2个ASCII合并为1个16进制
//printf("temp1:%02x\n", temp1);
//printf("temp2:%02x\n", temp2);
//printf("3pdata[%d]:%02x\n", j-1, pdata[j-1]);
}
#if 0
//计算校验
unsigned char lsrc = count_lrc(pdata, 1, 6);
pdata[j-1] = lsrc;
#endif
/*添加帧尾,构成原始帧数据*/
pdata[j++] = 0x0D;
pdata[j++] = 0x0A;
*dest_len = (j+1); //再添加帧头1个字节
/*帧头不参与处理*/
memcpy(&dest[1],pdata,j);
/*释放内存*/
free(pdata);
pdata = NULL;
return 0;
}
/*
把modbus ascii数据转换成16进制（改变原始数据和长度）
pbuf：原始数据 16进制显示：3A 30 30 30 33 30 30 32 30 30 30 30 32 64 62 0D 0A ，对应字符串:000300200002db 转换结果--》3a 00 03 00 20 00 02 db 0d 0a
src_len：原始数据长，结果会改变长度
例：
unsigned char p2[]="\x3A\x30\x30\x30\x33\x30\x30\x32\x30\x30\x30\x30\x32\x64\x62\x0D\x0A";
int len = 17;
convert_modbus_ascii_2hex_changesrc(p2, &len);
printf("len:%d,%02x\n", len, len);
for(int i = 0; i< len; i++)
{
printf("%02x ", p2[i]);
}
printf("\n");
结果：
dest_len:10,0a
3a 00 03 00 20 00 02 db 0d 0a
*/
unsigned char convert_modbus_ascii_2hex_changesrc(unsigned char *pbuf,int *src_len)
{
int len_befor_after = 2;
unsigned char *pdata,temp1,temp2;
int32u i=0,j=0,sum=0;
if(pbuf==0 || src_len==NULL || *src_len==0) return 1;
if((pdata = (unsigned char *)malloc((*src_len+1)*sizeof(unsigned char))) == NULL) return 2; //内存申请,目前采用堆空间
sum = (*src_len - len_befor_after); //帧头不参与
for(i = 1; i < sum; i+=2)
{
//printf("1pbuf[%d]:%02x\n", i, pbuf[i]);
switch(pbuf[i])
{
case 0x20: //代表空格
temp1 = 0x00;
break;
case 0x30:
temp1 = 0x00;
break;
case 0x31:
temp1 = 0x01;
break;
case 0x32:
temp1 = 0x02;
break;
case 0x33:
temp1 = 0x03;
break;
case 0x34:
temp1 = 0x04;
break;
case 0x35:
temp1 = 0x05;
break;
case 0x36:
temp1 = 0x06;
break;
case 0x37:
temp1 = 0x07;
break;
case 0x38:
temp1 = 0x08;
break;
case 0x39:
temp1 = 0x09;
break;
case 0x41:
temp1 = 0x0A;
break;
case 0x42:
temp1 = 0x0B;
break;
case 0x43:
temp1 = 0x0C;
break;
case 0x44:
temp1 = 0x0D;
break;
case 0x45:
temp1 = 0x0E;
break;
case 0x46:
temp1 = 0x0F;
break;
case 0x61:
temp1 = 0x0a;
break;
case 0x62:
temp1 = 0x0b;
break;
case 0x63:
temp1 = 0x0c;
break;
case 0x64:
temp1 = 0x0d;
break;
case 0x65:
temp1 = 0x0e;
break;
case 0x66:
temp1 = 0x0f;
break;
default:
temp1 = 0;
break;
}
//printf("2pbuf[%d]:%02x\n", i+1, pbuf[i+1]);
switch(pbuf[i+1])
{
case 0x20: //代表空格
temp2 = 0x00;
break;
case 0x30:
temp2 = 0x00;
break;
case 0x31:
temp2 = 0x01;
break;
case 0x32:
temp2 = 0x02;
break;
case 0x33:
temp2 = 0x03;
break;
case 0x34:
temp2 = 0x04;
break;
case 0x35:
temp2 = 0x05;
break;
case 0x36:
temp2 = 0x06;
break;
case 0x37:
temp2 = 0x07;
break;
case 0x38:
temp2 = 0x08;
break;
case 0x39:
temp2 = 0x09;
break;
case 0x41:
temp2 = 0x0A;
break;
case 0x42:
temp2 = 0x0B;
break;
case 0x43:
temp2 = 0x0C;
break;
case 0x44:
temp2 = 0x0D;
break;
case 0x45:
temp2 = 0x0E;
break;
case 0x46:
temp2 = 0x0F;
break;
case 0x61:
temp2 = 0x0a;
break;
case 0x62:
temp2 = 0x0b;
break;
case 0x63:
temp2 = 0x0c;
break;
case 0x64:
temp2 = 0x0d;
break;
case 0x65:
temp2 = 0x0e;
break;
case 0x66:
temp2 = 0x0f;
break;
default:
temp2 = 0;
break;
}
pdata[j++] = ((temp1 & 0x0F) << 4 | temp2); //2个ASCII合并为1个16进制
//printf("temp1:%02x\n", temp1);
//printf("temp2:%02x\n", temp2);
//printf("3pdata[%d]:%02x\n", j-1, pdata[j-1]);
}
#if 0
//计算校验
unsigned char lsrc = count_lrc(pdata, 1, 6);
pdata[j-1] = lsrc;
#endif
/*添加帧尾,构成原始帧数据*/
pdata[j++] = 0x0D;
pdata[j++] = 0x0A;
*src_len = (j+1); //再添加帧头1个字节
/*帧头不参与处理*/
memcpy(&pbuf[1],pdata,j);
/*释放内存*/
free(pdata);
pdata = NULL;
return 0;
}
int main(int argc, char *argv[])
{
//===1======16进制ASCII 转16进制测试===============//
unsigned char lsrc = 0;
unsigned char src[]="\x3A\x00\x03\x00\x20\x00\x02\xDB\x0D\x0A";
lsrc = count_lrc(src, 1, 6);
printf("lsrc:%d,%02x\n", lsrc, lsrc);
unsigned char dest[512] = {0};
//3A 30 30 30 33 30 30 32 30 30 30 30 32 64 62 0D 0A //:000300200002db
unsigned char p[]="\x3A\x30\x30\x30\x33\x30\x30\x32\x30\x30\x30\x30\x32\x64\x62\x0D\x0A";
int src_len = 17;
int dest_len = 0;
convert_modbus_ascii_2hex(p, src_len, dest, &dest_len);
printf("dest_len:%d,%02x\n", dest_len, dest_len);
for(int i = 0; i< dest_len; i++)
{
printf("%02x ", dest[i]);
}
printf("\n");
unsigned char p2[]="\x3A\x30\x30\x30\x33\x30\x30\x32\x30\x30\x30\x30\x32\x64\x62\x0D\x0A";
int len = 17;
convert_modbus_ascii_2hex_changesrc(p2, &len);
printf("len:%d,%02x\n", len, len);
for(int i = 0; i< len; i++)
{
printf("%02x ", p2[i]);
}
printf("\n");
//===2======16进制转16进制ASCII测试===============//
unsigned char ascii1[30]={0};
unsigned char ascii2[30]={0};
int ascii1_len = 7;
int ascii2_len = 7;
memcpy(ascii1, "\x00\x03\x00\x20\x00\x02\xdb", ascii1_len);
memcpy(ascii2, "\x00\x03\x00\x20\x00\x02\xdb", ascii2_len);
hex2ascii_lowercase(ascii1, &ascii1_len);
printf("ascii1_len:%d,%02x\n", ascii1_len, ascii1_len);
for(int i = 0; i< ascii1_len; i++)
{
printf("%02x ", ascii1[i]);
}
printf("\n");
hex2ascii_biggercase(ascii2, &ascii2_len);
printf("ascii2_len:%d,%02x\n", ascii2_len, ascii2_len);
for(int i = 0; i< ascii2_len; i++)
{
printf("%02x ", ascii2[i]);
}
printf("\n");
return 0;
}
相关推荐
- Sublime Text 4 稳定版 Build 4113 发布
-
IT之家7月18日消息知名编辑器SublimeText4近日发布了Build4113版本，是SublimeText4的第二个稳定版。IT之家了解到，SublimeTe...
- 【小白课程】openKylin便签贴的设计与实现
-
openKylin便签贴作为侧边栏的一个小插件，提供便捷的文本记录和灵活的页面展示。openKylin便签贴分为两个部分：便签列表...
- 壹啦罐罐 Android 手机里的 Xposed 都装了啥
-
这是少数派推出的系列专题，叫做「我的手机里都装了啥」。这个系列将邀请到不同的玩家，从他们各自的角度介绍手机中最爱的或是日常使用最频繁的App。文章将以「每周一篇」的频率更新，内容范围会包括iOS、...
- 电气自动化专业词汇中英文对照表（电气自动化专业英语单词）
-
专业词汇中英文对照表...
- Python界面设计Tkinter模块的核心组件
-
我们使用一个模块，我们要熟悉这个模块的主要元件。如我们设计一个窗口，我们可以用Tk()来完成创建；一些交互元素，按钮、标签、编辑框用到控件；怎么去布局你的界面，我们可以用到pack()、grid()...
- 以色列发现“死海古卷”新残片（死海古卷是真的吗）
-
编译｜陈家琦据艺术新闻网（artnews.com）报道，3月16日，以色列考古学家发现了死海古卷（DeadSeaScrolls）新残片。新出土的羊皮纸残片中包括以希腊文书写的《十二先知书》段落，这...
- 鸿蒙Next仓颉语言开发实战教程:订单列表
-
大家上午好，最近不断有友友反馈仓颉语言和ArkTs很像，所以要注意不要混淆。今天要分享的是仓颉语言开发商城应用的订单列表页。首先来分析一下这个页面，它分为三大部分，分别是导航栏、订单类型和订单列表部分...
- 哪些模块可以用在 Xposed for Lollipop 上?Xposed 模块兼容性解答
-
虽然已经有了XposedforLollipop的安装教程，但由于其还处在alpha阶段，一些Xposed模块能不能依赖其正常工作还未可知。为了解决大家对于模块兼容性的疑惑，笔者尽可能多...
- 利用 Fluid 自制 Mac 版 Overcast 应用
-
我喜爱收听播客，健身、上/下班途中，工作中，甚至是忙着做家务时。大多数情况下我会用MarcoArment开发的Overcast（Freemium）在iPhone上收听，这是我目前最喜爱的Po...
- 浅色Al云食堂APP代码(三)（手机云食堂）
-
以下是进一步优化完善后的浅色AI云食堂APP完整代码，新增了数据可视化、用户反馈、智能推荐等功能，并优化了代码结构和性能。项目结构...
- 实战PyQt5: 121-使用QImage实现一个看图应用
-
QImage简介QImage类提供了独立于硬件的图像表示形式，该图像表示形式可以直接访问像素数据，并且可以用作绘制设备。QImage是QPaintDevice子类，因此可以使用QPainter直接在图...
- 滚动条隐藏及美化（滚动条隐藏但是可以滚动）
-
1、滚动条隐藏背景/场景：在移动端，滑动的时候，会显示默认滚动条，如图1://隐藏代码：/*隐藏滚轮*/.ul-scrool-box::-webkit-scrollbar,.ul-scrool...
- 浅色AI云食堂APP完整代码(二)（ai 食堂）
-
以下是整合后的浅色AI云食堂APP完整代码，包含后端核心功能、前端界面以及优化增强功能。项目采用Django框架开发，支持库存管理、订单处理、财务管理等核心功能，并包含库存预警、数据导出、权限管理等增...
欢迎 你 发表评论:
- 一周热门
- 最近发表
- 标签列表
-
- idea eval reset (50)
- vue dispatch (70)
- update canceled (42)
- order by asc (53)
- spring gateway (67)
- 简单代码编程 贪吃蛇 (40)
- transforms.resize (33)
- redisson trylock (35)
- 卸载node (35)
- np.reshape (33)
- torch.arange (34)
- npm 源 (35)
- vue3 deep (35)
- win10 ssh (35)
- vue foreach (34)
- idea设置编码为utf8 (35)
- vue 数组添加元素 (34)
- std find (34)
- tablefield注解用途 (35)
- python str转json (34)
- java websocket客户端 (34)
- tensor.view (34)
- java jackson (34)
- vmware17pro最新密钥 (34)
- mysql单表最大数据量 (35)
